Electro-Voice EKX-15 Passive 15" 2-Way Speaker

Regular price $1,099.00 USD
Regular price Sale price $1,099.00 USD
Sale Sold out
Shipping calculated at checkout.

Description

The EKX series is the newest member of the Electro-Voice portable loudspeaker family. It combines legendary EV sound quality and reliability with the latest technology, all in a compact package that is suitable for a wide range of sound reinforcement scenarios, including musicians, DJs, installations and other sound applications. The EKX-15 features a 15" LF driver and a 1" titanium compression driver.

EV-engineered components and EVs patented Signal Synchronized Transducers (SST) waveguide design combine to provide precise coverage and superior sound quality at high SPLs. EVs award-winning industrial design ” with robust wood enclosures and durable EVCoat finish ” ensures that EKX speakers look as great as they sound. EKX-15 delivers up to 132 dB SPL utilizing high-sensitivity transducers designed and engineered by EV (15-inch EVS-15M woofer coupled with a DH-1M 1-inch titanium compression driver).

EKX passive models are ideal for portable and installed applications, with lightweight and compact 15-mm wood enclosures with internal bracing, durable EVCoat finish, eight (8) M10 threaded mounting points, aluminum pole-mounts, and all-metal handles.
Features
Speaker configuration
  • Active/passive: Passive
  • Type: 2-Way full range
  • LF driver: 15"
  • MF driver: Not applicable
  • HF driver: 1"
Power amp (active)
  • Amplifier type: Not applicable
  • Wattage: Not applicable
  • Mixer/preamp: Not applicable
  • Power capacity (passive)
  • 8 Ohms program/peak: 400W/1600W
  • 4 Ohms program/peak: Not applicable
  • Included power amp: No
Audio
  • Frequency response: 50Hz - 20kHz
  • Coverage pattern: 90 x 60
  • Max SPL: 132 dB
Enclosure
  • Construction: 15mm plywood
  • Width: 17.0"
  • Height: 27.0"
  • Depth: 16.9"
  • Weight: 51.5 lb.
Inputs
  • XLR: Not applicable
  • TRS: Not applicable
  • TS: Not applicable
  • RCA: Not applicable
  • SPEAKON: 1
Output/thru
  • XLR: Not applicable
  • TRS: Not applicable
  • RCA: Not applicable
  • SPEAKON: 1
Warranty
Microphones: 3 year full replacement
Wireless: 2 years
Speakers: 3 years active, 5 years passive
